/*c4droid代码手册
*sdl2实现触控
*傻傻_痴痴编写
*TTHHT收集整理
*转载请说明出处
*/
#include "SDL2/SDL.h"
#include "SDL2/SDL_ttf.h"
#include "SDL2/SDL_thread.h"
#include<stdio.h>
#include<string.h>
#define W 480
#define H 800
TTF_Font *font = NULL; //定义一个字体
SDL_Color color = { 178, 34, 34 };// 设置字体颜色
float x = 0, y = 0;// 用于获取触控位置的坐标
char ch[10];
//用于储存x,y为字符串输出
SDL_Thread*th=NULL;
SDL_Event event; //定义一个事件
SDL_Surface *sur1 = NULL; //定义刷屏表面
SDL_Surface *sur2 = NULL; //定义一个Surface表面用于显示字体
SDL_Window *w = NULL;// 创建一个窗口指针
SDL_Renderer *ren = NULL;// 创建一个渲染器指针
SDL_Texture *tex1 = NULL;
SDL_Texture *tex2 = NULL;//在SDL2.0中得把Surface表面传递给Texture来实现硬件加速,再把图形显示在屏幕上
SDL_Rect image;
//设置一个矩形用于显示surface表面大小,如果不使用image的话图像拉伸得无法想象
void setFont()
{
TTF_Init();// 启动font
font = TTF_OpenFont("/system/fonts/DroidSansFallback.ttf", 50);// 打开系统自带字体并设置大小为50
}
int getTouch(void*data)
{
while (1)
{
while (SDL_PollEvent(&event))
{
if (event.type == SDL_FINGERDOWN || event.type == SDL_FINGERMOTION)
//当事件为触屏
{
x = event.tfinger.x;
y = event.tfinger.y;
//获取x,y的坐标
}
}
}
}
int main(int argc, char *argv[])
{
bool q=false;
image.x = 0;
image.y = 100;
image.h = 150;
image.w = 500;
w = SDL_CreateWindow("Touch Test",0,0,W,H,SDL_WINDOW_OPENGL|SDL_WINDOW_RESIZABLE|SDL_WINDOW_BORDERLESS);// 配置窗口参数并创建
ren = SDL_CreateRenderer(w, -1, SDL_RENDERER_PRESENTVSYNC);// 为创建的窗口配置渲染器
sur1 = SDL_CreateRGBSurface(0, W, H, 32, 0, 0, 0, 0); //用于画一个矩形来刷屏
SDL_FillRect(sur1, NULL, 0xffacca);
//在sur1上画一个矩形
tex1 = SDL_CreateTextureFromSurface(ren, sur1); //把sur1传递给tex1
setFont();
th=SDL_CreateThread(getTouch,NULL,NULL);
while (q==false )
{
SDL_RenderClear(ren);
sprintf(ch, "X: %f Y: %f",100*x,100*y); //把坐标位置储存到ch字符串中,这里乘以100为了显示更方便直观
sur2=TTF_RenderUTF8_Blended(font,ch,color); //让字符串生成surface表面并且传递给sur2
tex2 = SDL_CreateTextureFromSurface(ren, sur2);
SDL_FreeSurface(sur2);
SDL_RenderCopy(ren, tex1, NULL, NULL); //SDL2.0中是使用SDL_RenderCopy直接把
