= Mapper 001 =
========================
aka
--------------------------
MMC1
SxROM
Example Games:
--------------------------
Final Fantasy
Mega Man 2
Blaster Master
Metroid
Kid Icarus
Zelda
Zelda 2
Castlevania 2
Notes:
---------------------------
MMC1 is unique in that not only must the registers be written to *one bit at a time*, but also you cannot
write to the registers directly.
Internal registers are 5 bits wide. Meaning to complete a "full" write, games must write to a register 5
times (low bit first). This is usually accomplished with something like the following:
LDA value_to_write
STA $9FFF ; 1st bit written
LSR A
STA $9FFF ; 2nd bit written
LSR A
STA $9FFF ; 3rd bit written
LSR A
STA $9FFF ; 4th bit written
LSR A
STA $9FFF ; final 5th bit written -- full write is complete
Writing to anywhere in $8000-FFFF will do -- however the address you write to on the last of the 5 writes
will determine which internal register gets filled. The address written to for the first 4 writes *does not
matter at all*... though games generally write to the same address anyway (like in the above example).
To illustrate this:
LDA #$00 ; we want to write 0 to a reg
STA $8000
STA $8000
STA $8000
STA $8000 ; first 4 writes go to $8000
STA $E000 ; 5th write goes to $E000
The above code will affects reg $E000 only Despite $8000 being written to several times, reg $8000
remains totally unchanged
How this works is that when the game writes to $8000-FFFF, it goes to a hidden temporary register. That
register records the bits being written. Only after all 5 bits are written does the final 5-bit value move
to the desired *actual* register.
Only bits 7 and 0 are significant when writing to a register:
Temporary reg port ($8000-FFFF):
[r... ...d]
r = reset flag
d = data bit
When *r* is set:
- *d* is ignored
- hidden temporary reg is reset (so that the next write is the "first" write)
- bits 2,3 of reg $8000 are set (16k PRG mode, $8000 swappable)
- other bits of $8000 (and other regs) are unchanged
When *r* is clear:
- *d* proceeds as the next bit written in the 5-bit sequence
- If this completes the 5-bit sequence:
- temporary reg is copied to actual internal reg (which reg depends on the last address written to)
- temporary reg is reset (so that next write is the "first" write)
Confusing? Yeah it looks confusing, but isn*t really. For an example:
LDA #$00
STA $8000 ; 1st write (*r* bit is clear)
STA $8000 ; 2nd write
LDA #$80
STA $8000 ; reset (*r* bit is set)
LDA #$00
STA $8000 ; 1st write (not 3rd)
Variants:
--------------------------
There are also a slew of board variations which are assigned to mapper 001 as well. See the sections at the
bottom for details. Determining which variant a game uses is difficult -- likely you*ll need to fall back
to a CRC or hask check.
Registers:
--------------------------
Note again, these registers are internal and are not accessed directly Read notes above.
$8000-9FFF: [...C PSMM]
C = CHR Mode (0=8k mode, 1=4k mode)
P = PRG Size (0=32k mode, 1=16k mode)
S = Slot select:
0 = $C000 swappable, $8000 fixed to page $00 (mode A)
1 = $8000 swappable, $C000 fixed to page $0F (mode B)
This bit is ignored when *P* is clear (32k mode)
M = Mirroring control:
%00 = 1ScA
%01 = 1ScB
%10 = Vert
%11 = Horz
$A000-BFFF: [...C CCCC]
CHR Reg 0
$C000-DFFF: [...C CCCC]
CHR Reg 1
$E000-FFFF: [...W PPPP]
W = WRAM Disable (0=enabled, 1=disabled)
P = PRG Reg
Disabled WRAM cannot be read or written. Earlier MMC1 versions apparently do not have this bit implimented.
Later ones do.
CHR Setup:
--------------------------
There are 2 CHR regs and 2 CHR modes.
$0000 $0400 $0800 $0C00 $1000 $1400 $1800 $1C00
+---------------------------------------------------------------+
C=0: | <$A000> |
+---------------------------------------------------------------+
C=1: | $A000 | $C000 |
+-------------------------------+-------------------------------+
PRG Setup:
--------------------------
There is 1 PRG reg and 3 PRG modes.
$8000 $A000 $C000 $E000
+-------------------------------+
P=0: | <$E000> |
+-------------------------------+
P=1, S=0: | { 0 } | $E000 |
+---------------+---------------+
P=1, S=1: | $E000 | {$0F} |
+---------------+---------------+
On Powerup:
----------------------------
This varies from version to version. Earlier MMC1 versions have no determined startup state. Later ones do.
- bits 2,3 of $8000 are set (16k PRG mode, $8000 swappable)
WRAM Disable varies wildly from version to version. Some versions don*t have it at all, other versions have
it cleared initially, others have it set initially, and others have it random. To be "safe", when
homebrewing, assume it*s disabled (and have your game explicitly enable it before accessing WRAM), and when
emudeving, assume it*s enabled at startup (or else some early MMC1 games will break in your emu).
Additional Notes:
----------------------------
Consecutive writes that are too close together are apparently ignored. One game where this is significant
is Bill & Ted*s Excellent Video Game Adventure. That game does the following HORRIBLY SLOPPY code to reset
the mapper:
INC $FFFF (where $FFFF contains $FF when read)
For those of you who really know your 6502... you know that this will read $FFFF (getting $FF), write that
value ($FF) back to $FFFF, increment it by one, then write the new value ($00) to $FFFF. This results in
two register writes: $FF, then $00.
Normally, such writes would reset the mapper, then write a single data bit. However if your emu does it
like that, the game will crash, as the game expects the next write to be the 1st in a 5-bit sequence (and
your emu will treat it like the 2nd).
However these writes are performed on consecutive CPU cycles -- which apparently are too close to each other.
As such, only the first write (of $FF) is acknowledged and performed, and the second write (of $00) is
ignored. Emulating in this manner results in a fully functioning game.
So while it is unsure exactly how far apart the writes must be, you can assume that the distance between
them must be at least 2 CPU cycles. Such that Read/Modify/Write instructions (like INC) will only
acknowledge the first write, but two consecutive write instructions (like 2 side-by-side STA*s) will work
normally.
-----------------------------------------
-----------------------------------------
Special Variant -- SUROM:
--------------------------
Example Games:
Dragon Warrior 4
Dragon Quest 4
The MMC1 PRG reg is only 4 bits wide. This means that normally, page $0F is the highest page number you can
access. With 16k pages... this limits typical MMC1 to 256k PRG ($10 pages * $4000 per page). SUROM
"hijacks" one of the bits from the CHR registers and uses it as an additional PRG bit. This allows for
access to $1F pages, allowing 512k PRG.
$A000-BFFF: [...C CCCC] CHR reg 0
[...P ....] hijacked PRG bit
$C000-DFFF: [...C CCCC] CHR reg 1
[...P ....] hijacked PRG bit
When in 4k CHR mode, *P* in both $A000 and $C000 *must* be set to the same value, or else pages will
constantly be swapped as graphics render In 8k CHR mode (which is what DQ4 uses), $C000 is irrelevent
since it is ignored, and $A000 is used exclusively.
The hijacked PRG bit selects which 256k block is used for *ALL* PRG... *including* fixed pages. Meaning
fixed page $0F @ $C000 can swap between page $0F and $1F.
Special Variant -- SOROM:
--------------------------
Example Games:
Nobunaga*s Ambition
Romance of the Three Kingdoms
Genghis Khan
SOROM has 16k PRG-RAM (instead of the typical 8k), and hijacks unused bits from the CHR regs in order to
select which 8k PRG-RAM page is at $6000-7FFF. The first 8k of PRG-RAM (page 0) is not battery backed --
but the second 8k is.
When in 4k CHR Mode:
$A000-BFFF: [...R ...C]
R = PRG-RAM page select
C = CHR reg 0
$C000-DFFF: [...R ...C]
R = PRG-RAM page select
C = CHR reg 1
In 4k CHR mode, above *R* bits MUST be set to the same value or else PRG-RAM will automatically swap as
the PPU fetches tiles to render
When in 8k mode:
$A000-BFFF: [.... R...] PRG-RAM page select
$C000-DFFF: [.... ....] Unused
Special Variant -- SXROM:
--------------------------
Example Games:
Final Fantasy 1 & 2 (the combo cart, not the individual games)
Best Play Pro Yakyuu Special
SXROM is sort of like a combination of SUROM and SOROM. It uses bits from CHR regs to have an additional
PRG bit, and also to have swappable PRG-RAM. SXROM has a whopping 32k PRG-RAM (all of which can be battery
backed).
When in 8k CHR mode:
$A000-BFFF: [...P RR..]
P = PRG-ROM 256k block select (just like on SUROM)
R = PRG-RAM page select (selects 8k @ $6000-7FFF, just like SOROM)
I*m uncertain of behavior when in 4k CHR mode. I suspect it is similar to SUROM, in that the registers must
be identical or else undesired swapping will occur as the PPU renders.
